Description
| Production dimension (L/W/H *mm) | 1010×285×485 | Splitting stroke Length（mm） | 560 |
| Net weight (KG) | 41.5 | Splitting diameter φ（mm） | 50-400 |
| Packing size (mm) | 1040×300×540 | Operating method | single-handed valve |
| Total weight of packing (KG) | 53 | Max. tonnage | 8T |
| Horizontal/Vertical | Horizontal | Hydraulic oil No. | 32#/46# |
| Splitting method (optional) | 2 ways/4 ways | Tires | 5-1.5 |
| Cycle | 13s | Hydraulic oil | 3.6L |
| Working voltage/Hz | 220V/50Hz | Inner diameter of cylinder（mm） | 55 |
| Motor power | 2.2kW | Piston diameter（mm） | 30 |
| Protection level | IP54 | OEM | Acceptable |
