Description
| Model | PL1220 |
| Max processing length | 1200mm |
| Max turning diameter | 200mm |
| Air pressure | 0.6-0.8Mpa |
| Power supply | AC 380V 3 phase 50HZ/60HZ（Customized voltage 220V） |
| Max feed rate | 2000mm/min |
| Min setting unit | 0.01cm |
| Transmission type | Ball screw for Y axis |
| Main shaft rotating speed | 0-3000r/min |
| Motor power | 4kw |
| Cutter material | Hard alloy blade |
| Control System | Lcd screen control system |
| Hand controller recognise file | *.dxf |
| Drawing Software | AutoCAD |
| Command Language | G code |
| Size | 2300*1100*1000mm |
