Description
| Model | PK2040 ATC |
| X,Y,Z Working Area | 2000*4000*200 mm |
| Spindle brand | CC/JST (Top brands in China) |
| Spindle power | 9KW（ ISO30）（air cooling spindle） |
| Drive motor brand | Leadshine (Top brand in China |
| Drive motor | Servo motor 1.5KW*3 |
| Inverter power | 11KW |
| Tool change speed | High-speed switching |
| Air pressure | 0.7 Mpa |
| Double bag dust collector | 5.5KW |
| Spindle Speed | 0-24000 rpm |
| Machining accuracy | +-0.02mm |
| Maximum working speed | 20000mm/min |
| Maximum travel speed | 80000mm/min |
| Number of positioning cylinders | X（3）+Y（8） position cylinder |
| Number of tools | 12 tools automatic switching |
| Vacuum adsorption pump power | 7.5 KW |
| Overall dimension | 5080x3000x2400 mm |
| N.W. | 2550 KG |
