MZ73213B

Horizontal Woodworking Furniture Multi Spindles Wood Drilling 3 Row Boring Machine for Mdf Plywood Panel

Category: Tag:

Description

we can provide integrated woodworking machinery solutions for your project.

Phoenix Machinery offers a variety of structural and performance models suitable for wood and roll edge banding materials

Model MZ73213B
Maximum Drilling Diameter Max.=35mm(Single drilling)
D=13mm(Multiple drilling)
Max Drill Diameter 60mm
Vertical machining holes distance 140-2400mm
Number of auger spindle 21 bits * 3lines
Maximum Drilling Depth 60mm
Rotational Speed 2840r/min
Motor power 1.5kw * 3
Air Pressure 0.6-0.8MPa
Suitable voltage 380V 50HZ (Customized voltage)
Weight 1000kg
Installation size 3400*2500*1600mm
