MM2012

Wood round bar sander, the main components include a base, a fuselage and a transmission and feeding device,The belt and the rubber wheel move in opposite directions, so that the round rod to be processed enters from the feeding end and rotates automatically, sanding and polishing during the rotation, and adjusting the angle of the rubber wheel by adjusting the bolt, according to the round rod The size and processing precision requirements achieve the purpose of adjusting the feeding speed. The utility model has the advantages of high production efficiency, safe operation, good sanding and polishing effect.

It have Single belt round bar sander and double belt round bar sander two type.

Description

we can provide integrated woodworking machinery solutions for your project.

Phoenix Machinery offers a variety of structural and performance models suitable for wood and roll edge banding materials

Model MM2012
Voltage 380V
Motor Power 2.2kw
feeding speed 5-10m/min
Spindle speed 1420r/min
Feeding Rolls Speed 70r/min
Minimum size 80mm
Sanding Belt Roll Speed 890mm/min
Sanding Belt Specification 1820*120mm
Machining Diameter Range 10-60mm
Dimension 880*900*1400mm
Weight 200kg
