MJ3200

Precision Slide Table Saw 45/90 Degree Cutting with 3200mm Slide Table Length for Wood Based Panels Machinery

Category: Tag:

Description

we can provide integrated woodworking machinery solutions for your project.

Phoenix Machinery offers a variety of structural and performance models suitable for wood and roll edge banding materials

PANEL SAW MODEL MJ3200
Max cutting length 3100mm
Sliding table length 3200mm
Sliding table width 430mm
Main saw blade diameter 300mm
Scoring saw blade diameter 120mm
Main saw spindle speed 4000-6000rpm
Scoring saw spindle speed 9000rpm
Main spindle diameter 30mm
Scoring spindel diameter 20mm
Tilting saw blade 45°-90°
Height of cut at 45° 55mm
Height of cut at 90° 80mm
Main motor 5.5KW
Scoring motor 1.1KW
Electric lift Including
Angle digital display Including
Package size Sliding table: 3400*480*280mm
Body: 2200*1250*1000mm
Gross weight 950kg
