MB204F

Electric lifting Multi-purpose Flat Planer Woodworking Solid Furniture Factory Press Planer

Category: Tag:

Description

we can provide integrated woodworking machinery solutions for your project.

Phoenix Machinery offers a variety of structural and performance models suitable for wood and roll edge banding materials

Model MB204F MB205F MB206F MB208F
Max.working width 410mm 510mm 630mm 810mm
Max.working thickness 200mm 200mm 200mm 200mm
Max.planing depth 3mm/2mm 3mm/2mm 3mm/2mm 3mm/2mm
Mini.working length 200mm 200mm 200mm 200mm
Spindle speed 7000rpm 7000rpm 7000rpm 7000rpm
Main spindle power 5.5KW+4KW 5.5KW+4KW 5.5KW+4KW 7.5KW+5.5KW
Feeding motor power 1.1KW*2 1.1KW*2 1.1KW*2 1.5KW*2
Diameter of spindle 76mm 76mm 76mm 76mm
Feeding speed 0-20m/min 0-20m/min 0-20m/min 0-20m/min
Size 1840*850*1450mm 1840*950*1450mm 1840*1050*1450mm 1840*1250*1450mm
Weight 780KG 850KG 930KG 1070KG
